FRAME FAMILY
Haibike, SDURO HardSeven, Aluminium 6061, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount
-
FORK
RockShox, 35 Gold RL, Air, Travel= 120 mm, 15 x 110mm thru-axle Boost
-
REAR DERAILLEUR
Sram, SX Eagle
-
SHIFT LEVER
Sram, SX Eagle, Trigger switch, 12 speed
-
SPROCKET
Sram, Eagle PG1210, 11 - 50 teeth
-
BOTTOM BRACKET
integrated in the motor
-
CRANK ARM
Haibike Components, The Crank ++, Aluminium
-
CHAIN
Sram, SX Eagle
-
CHAIN GUIDE
Haibike aluminium/Nylon directmount
-
CHAINRING
Sram, 38 teeth
-
BRAKE LEVER
Shimano, MT401, Aluminium
-
BRAKE DISC (FRONT)
Shimano, RT30-L
-
BRAKE (FRONT)
Shimano, MT420, 203 mm, 4-piston disc brake
-
BRAKE DISC (REAR)
Shimano, RT30-M
-
BRAKE (REAR)
Shimano, MT420, 180 mm, 4-piston disc brake
-
TUBE
Presta valve
-
TYRE
Schwalbe, Nobby Nic Evo SnakeSkin, 70-584, 27.5" x 2.80"
-
RIM (REAR)
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
-
RIM
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
-
FRONT WHEEL HUB
Shimano, MT400-B, Centerlock
-
REAR WHEEL HUB
Shimano, Centerlock
-
SPOKES
Sapim, Leader, black
-
HANDLEBAR
Haibike Components, TheBar ++, 740 mm
-
GRIPS
Haibike, MTB grips
-
STEM
Haibike Components, TheStem 2, A-head, Bar bore: 31.8 mm
-
HEADSET
Feimin, A-Head Tapered, Aluminium, cartridge bearing
-
SADDLE
Haibike Components, TheSaddle
-
SEAT POST
Haibike Components, TheSeatpost ++, 31.6 mm, Aluminium
-
PEDALS
Freeridepedal, Aluminium, with Reflector
-
CLAMPING RING
Quick release, 34.9 mm
-
ENGINE
Bosch, Performance CX, 250 W, 75 Nm, 25 km/h
-
WEIGHT (KG)
23.1 kg
-
PERMITTED TOTAL WEIGHT
120.0 kg
-
BATTERY
Bosch, PowerTube, 500 Wh
