Frame Family
Haibike, SDURO Cross/Trekking, Aluminium 6061, Quick-release 5 x 135mm, Disc brake Post Mount
Fork
SR Suntour, NEX E25-LO, Lockout, Steel spring, Travel= 63 mm, Steel steerer tube 1 1/8", Quick release 100mm
Rear Derailleur
Shimano, Alivio M4000
Shift Lever
Shimano, Alivio M4000, Rapidfire, 9 speed
Sprocket
Shimano, HG200, 11 - 36 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank +, Aluminium
Chain
KMC, e9S
Chain Guide
Nylon directmount
Chainring
Steel, 38 teeth
Brake Lever
Tektro, T275, Aluminium
Brake Disc (Front)
Tektro, TR180
Brake (Front)
Tektro, T275, 180 mm, 2-piston disc brake
Brake Disc (Rear)
Tektro, TR160
Brake (Rear)
Tektro, T275, 160 mm, 2-piston disc brake
Tube
Presta valve
Tyre
Schwalbe, Road Cruiser , 42-622, 28" x 1.60"
Rim
Ryde, Zac421, hollow rim, Aluminium
Front Wheel Hub
Haibike Components, TheHub +, 6-bolt standard
Rear Wheel Hub
Haibike Components, 6-bolt standard
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar +, 720 mm
Grips
XLC, Comfort bo3
Stem
Haibike Components, The Stem +, A-head
Headset
Feimin, A-Head Tapered, ball bearing
Saddle
Haibike Components, TheSaddle
Seat Post
Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Pedals
VP, E461, Aluminium, mit Reflektor
Headlight
Trelock, Bike - i Veo LS230, 20 lm
Rear Light
AXA, Blueline
Carrier
system carrier, 25.0 kg
Fenders
SKS, Chromoplastics
Stand
Ursus, Mooi, Rear stand
Clamping Ring
Quick release, 34.9 mm
Engine
Yamaha, PW-SE System, 250 W, 70 Nm, 25 km/h
Weight (Kg)
24.9 kg
Permitted Total Weight
130.0 kg
Battery
Yamaha, InTube, 400 Wh
