Frame Family
Haibike, SDURO Cross/Trekking, Aluminium 6061, Quick-release 5 x 135mm, Disc brake Post Mount
Fork
SR Suntour, NCX D-LO, Lockout, Steel spring, Travel= 63 mm, Steel steerer tube 1 1/8", Quick release 100mm
Rear Derailleur
Shimano, Deore XT T8000
Shift Lever
Shimano, Deore M6000, Rapidfire, 20 speed
Sprocket
Shimano, HG50, 11 - 36 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank +, Aluminium
Chain
KMC, e10S
Chainring
Aluminium, 48 teeth
Brake Lever
Shimano, MT401, Aluminium
Brake Disc (Front)
Shimano, RT30-M
Brake (Front)
Shimano, MT400, 180 mm, 2-piston disc brake
Brake Disc (Rear)
Shimano, RT30-S
Brake (Rear)
Shimano, MT400, 160 mm, 2-piston disc brake
Tube
Presta valve
Tyre
Schwalbe, Tyrago K-Guard, 42-622, 28.0" x 1.60"
Rim
Rodi, Black Rock 21, with eyelets, hollow rim, Aluminium
Front Wheel Hub
Shimano, M3050, Centerlock
Rear Wheel Hub
Shimano, Centerlock
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar ++, 740 mm
Grips
XLC, Comfort bo3
Stem
Haibike Components, TheStem ++, A-head, Bar bore: 31.8 mm, 6°
Headset
Feimin, A-Head Alloy 1 1/8", cartridge bearing
Saddle
Haibike Components, TheSaddle
Seat Post
Haibike Components, TheSeatpost ++, 31.6 mm, Aluminium
Pedals
VP, E461, Aluminium, mit Reflektor
Headlight
Haibike, Skybeamer 150, 50 lm
Rear Light
AXA, Blueline
Carrier
system carrier, 25.0 kg
Fenders
SKS, Chromoplastics
Stand
Ursus, Mooi, Rear stand
Clamping Ring
Quick release, 34.9 mm
Engine
Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h
Weight (Kg)
24.7 kg
Permitted Total Weight
130.0 kg
Battery
Yamaha, InTube, 500 Wh
