FRAME
C:62 Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
SIZE
29: M (18"), L (20"), XL (22")
FORK
Fox 36 Float Factory FIT4, 3-Position w/Low Speed Compression Adjust, Tapered, 15x110mm, E-Bike Optimized, 150mm, Kashima Coated
SHOCK
Fox Float X Factory, 205x60mm, Trunnion Mount, Adjustable LSC w/ 2-Pos. Lever, Kashima Coated
SHOCK HARDWARE
Top: 54mm Trunnion Mount, Bottom: 22.2x8mm
DRIVE UNIT
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
BATTERY
Bosch PowerTube 750
DISPLAY
Bosch Kiox 300
CHARGER
Bosch 4A
BRAKE SYSTEM
Shimano XT BR-M8120, Hydr. Disc Brake (203/203)
REAR DERAILLEUR
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
SHIFTERS
Shimano XT SL-M8100-IR, Direct Attach
CRANKSET
e*thirteen Plus Crank, 165mm, 34T
CHAIN GUIDE
Reverse Flip-Guide E-Kettenführung, Direct Mount, GEN4
CASSETTE
Shimano XT CS-M8100, 10-51T
CHAIN
Shimano CN-M8100
WHEELSET
Newmen Evolution SL E.G. 30, 28/28 Spokes, 15x110mm/12x148mm, Tubeless Ready
FRONT TIRE
Schwalbe Magic Mary, Super Trail, Addix Soft, Kevlar, 2.4
REAR TIRE
Schwalbe Big Betty, Super Gravity, Addix Soft, Kevlar, 2.4
STEM
CUBE Performance Stem E-MTB, 31.8mm
HANDLEBAR
Newmen Advanced 318.25, Carbon, 780mm
GRIPS
ACID Disrupt, Soft Compound
SEAT POST
Fox Transfer Factory 31.6mm, Kashima Coated (M,L: 150mm, XL: 175mm)
SEATCLAMP
CUBE Screwlock Semi Integrated, 34.9mm
SADDLE
Natural Fit Wreath
HEADSET
ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
WEIGHT
24,3 kg
COLOUR
actionteam
ART. NO
536253
PRICE
n/a
