SPECIFICATIONS
Essential
Shock: RockShox
Model year: 2022
Headset: FSA Orbit 1.5 ZS NO.57SC
Fork: RockShox RECON SILVER TK Boost 120mm (27.5 ") 46mm Rake Lapierre metric 190x40mm
Brakes: Shimano MT200 hydraulic disc brakes
Discs: Shimano RT30 203mm / 180mm
Shifters: Shimano Altus SLM2010 9s
Handlebar: Lapierre alloy 6061, Width: 740mm, Rise: 25mm, Ø: 31.8mm New Lapierre DD34 Lock-on
Stem: Lapierre alloy, 0 °, Ø: 31.8mm, L: 45mm
Frame: Overvolt OST + 120mm (27.5+ '') travel Yamaha Supreme 5 alloy boost (updated bracket for PW-ST compatible with added plastic top cover)
Electrical Specifications
Battery: Intube battery 500Wh / display A
Engine: Yamaha PWST 25kph
Comfort
Seatpost: Lapierre alloy, Ø: 31.6mm, L: 350mm
Seat: XLC by DDK
Wheels
Rims: Lapierre eAM + 32H, 35-584
Wheel size: 27.5 "
Tires: Schwalbe Smart Sam K-Guard 27.5x2.6
Drivetrain
Derailleur: Shimano Alivio RD-M3100, 9v Shadow
Chain: Chain: KMC E9S 9s
Crankset: Lapierre Overvolt Yamaha Narrow Wide 32T 170mm
Cassette: Sunrace CSM090 11-36T 9s
Hubs: Shimano MT400, boost thru axle
