ENGINE
Yamaha, PW-SE System, 250W, 70 Nm, 25 km/h
DISPLAY
Yamaha, side switch
BATTERY
Yamaha, InTube, 500 Wh
FRAME FAMILY
Haibike, Trekking Yamaha i500/i400, Aluminium 6061
FORK
SR Suntour, NEX E25, Steel spring, Travel = 63 mm, Steel steerer tube 1 1/8" - 1 1/2" tapered, Quick release 100mm
CRANK ARM
Haibike, forged, Aluminium
BRAKE (FRONT)
Tektro, T275, 180 mm, 2-piston disc brake
BRAKE (REAR)
Tektro, T275, 160 mm, 2-piston disc brake
TUBE
Presta valve
RIM
Schürmann, Yak25, with eyelets, hollow rim, Aluminium
CLAMPING RING
Quick release, 34.9 mm
REAR DERAILLEUR
Shimano, Deore M5120
SHIFT LEVER
Shimano, Deore M4100, Trigger switch, 10 Speed
BOTTOM BRACKET
Integrated in the motor
SPROCKET
Shimano, M4100, 11 - 46 teeth
CHAIN
KMC, e10S
CHAINRING
Steel, 38 teeth
BRAKE LEVER
Tektro, T275, Aluminium
BRAKE DISC (FRONT)
Tektro, TR180
BRAKE DISC (REAR)
Tektro, TR160
TYRE
Continental, Contact Cruiser, 62-584, 27.5" x 2.4"
FRONT WHEEL HUB
Haibike Components, 6-bolt standard
REAR WHEEL HUB
Haibike, 6-bolt standard
SPOKES
Sapim, Leader, Black
HANDLEBAR
XLC, Topflat, 720 mm
GRIPS
XLC, Comfort bo3
STEM
XLC, Alu, A-head
HEADSET
Cane Creek, Viscoset, Aluminium
SADDLE
XLC, Trekking
SEAT POST
XLC, Aluminium, Patent, 31.6 mm
PEDALS
VP, E461, Aluminium, with Reflector
HEADLIGHT
Haibike, Skybeamer 150, 50 lm
REAR LIGHT
AXA, Blueline
DYNAMO
Via system battery
CARRIER
Massload, system carrier
FENDERS
Eurofender, Tempo, Chromoplastics
STAND
Ursus, Mooi , Rear stand
PERMITTED TOTAL WEIGHT
130.0 kg
