ENGINE
Yamaha, PW-ST System, 250W, 70 Nm, 25 km/h
DISPLAY
Yamaha, Multi Switch, 2.8" TFT, 16 functions
BATTERY
InTube, 630 Wh
FRAME FAMILY
Haibike, Trekking Yamaha i630, Aluminium 6061
FORK
SR Suntour, Mobie A32, Steel spring, Travel= 75 mm, Aluminium steerer tube 1 1/8", 15 x 100mm thru-axle
CRANK ARM
Haibike, forged, Aluminium
BRAKE (FRONT)
Shimano, MT410, 180 mm, Hydraulic disc brakes
BRAKE (REAR)
Shimano, MT410, 180 mm, Hydraulic disc brakes
TUBE
Presta valve
RIM
Schürmann, Yak25, with eyelets, hollow rim, Aluminium
CLAMPING RING
Quick release, 34.9 mm
REAR DERAILLEUR
Shimano, Deore M5100
SHIFT LEVER
Shimano, Deore M5100, Trigger switch, 11 Speed
BOTTOM BRACKET
Integrated in the motor
SPROCKET
Shimano, M5100, 11 - 51 teeth
CHAIN
KMC, e11S
CHAINRING
Steel, 38 teeth
BRAKE LEVER
Shimano, MT402, Aluminium
BRAKE DISC (FRONT)
Shimano, RT30-M
BRAKE DISC (REAR)
Shimano, RT30-M
TYRE
WTB, Groov-E, 61-584, 27.5" x 2.4"
FRONT WHEEL HUB
Shimano, MT400-B, Centerlock
REAR WHEEL HUB
Shimano, MT410, Centerlock
SPOKES
Sapim, Leader, Black
HANDLEBAR
XLC, Topflat, 720 mm
GRIPS
XLC, Comfort bo3
STEM
XLC, Alu, A-head
HEADSET
Feimin, A-Head Tapered, Ball bearing
SADDLE
Selle Royal, Wave
SEAT POST
XLC, Aluminium, Patent, 31.6 mm
PEDALS
VP, E461, Aluminium, with Reflector
HEADLIGHT
Haibike, Skybeamer 150, 50 lm
REAR LIGHT
AXA, Juno Ebike
DYNAMO
Via system battery
CARRIER
Massload, System carrier
FENDERS
Eurofender, Tempo, Chromoplastics
STAND
Ursus, Mooi , Rear stand
PERMITTED TOTAL WEIGHT
130.0 kg
INCLUDES eCONNECT
No
