Haibike Trekking 5 Specifications
ENGINE
Yamaha, PW-S2, 250W, 75 Nm
DISPLAY
Side Switch
BATTERY
InTube, 720 Wh
FORK
SR Suntour, Mobie 25 LOR, Lockout, Steel spring, travel= 100 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 100mm thru-axle
CRANK ARM
Miranda, Kies
BRAKE (FRONT)
Shimano, MT410, Hydraulic disc brakes
BRAKE (REAR)
Shimano, MT410, Hydraulic disc brakes
TUBE
Dunlop valve
RIM
Schürmann, Yak25, with eyelets, hollow rim, Aluminium
CLAMPING RING
Quick Release, Quick release, 38.1 mm
REAR DERAILLEUR
Shimano, Deore M5100
SHIFT LEVER
Shimano, Deore M5100, Trigger switch
BOTTOM BRACKET
integrated in the motor
SPROCKET
Shimano, M5100, 11 - 51 teeth
CHAIN
Shimano, CN-M6100
CHAINRING
Steel, 38 teeth
CHAIN GUIDE
Nylon directmount
BRAKE LEVER
Shimano, MT402, Aluminium,
BRAKE DISC (FRONT)
Shimano, RT30-M, 180 mm
BRAKE DISC (REAR)
Shimano, RT30-M, 180 mm
TYRE
Continental, Ruban Reflex, 27.5" x 2.3"
FRONT WHEEL HUB
Shimano, MT400, Centerlock
REAR WHEEL HUB
Shimano, MT400-B, Centerlock
SPOKES
Sapim, Leader, Black
HANDLEBAR
Ergoriser, oversize, 720 mm
STEM
XLC, A-Head verstellbar, A-head, 31.8 mm
HEADSET
Feimin, A-Head Tapered, Aluminium, Cartridge
SADDLE
Selle Royal, Essenza
SEAT POST
Aluminium, Patent, 34.9 mm
PEDALS
VP, E461, Aluminium, with Reflector
HEADLIGHT
Herrmans, H-Black MR4, 40 lm
REAR LIGHT
Spanninga, Aerline 2 Brake
DYNAMO
via system battery
CARRIER
Systemgepäckträger MIK, 25 kg
FENDERS
Curana, Apollo 70, Aluminium
STAND
Ursus, Mooi, Rear stand
PERMITTED TOTAL WEIGHT
130.0 kg
GEAR SHIFT
Shimano
