Damper
RockShox, Deluxe Select Plus, Air, 65.0 mm
Frame Family
Haibike, SDURO FullSeven LT, Aluminium 6061, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount, Travel= 150 mm
Fork
RockShox, Yari RC, Air, Travel= 150 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 100mm thru-axle
Rear Derailleur
Shimano, Deore XT M786
Shift Lever
Shimano, Deore M6000, Rapidfire, 20 speed
Sprocket
Shimano, HG50, 11 - 36 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank ++, Aluminium
Chain
KMC, e10S
Chainring
Aluminium, 44 teeth
Brake Lever
Shimano, Deore XT M8000, Aluminium
Brake Disc (Front)
Shimano, RT70-L
Brake (Front)
Shimano, Deore XT M8020, 203 mm, 4-piston disc brake
Brake Disc (Rear)
Shimano, RT70-M
Brake (Rear)
Shimano, Deore XT M8020, 180 mm, 4-piston disc brake
Tube
Presta valve
Wheel Set
DT Swiss, H1900
Tyre
Schwalbe, Nobby Nic Evo SnakeSkin, 70-584, 27.5" x 2.80"
Rim (Rear, If Different)
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Rim
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Front Wheel Hub
Shimano, MT400-B, Centerlock
Rear Wheel Hub
Shimano, Centerlock
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar +++ Gravity, 780 mm
Grips
Haibike, MTB grips
Stem
Haibike Components, TheStem 2, A-head, Bar bore: 31.8 mm
Headset
Feimin, A-Head Tapered, Aluminium, cartridge bearing
Saddle
Haibike Components, TheSaddle
Seat Post
XLC, AllMtn, Remote, Telescope, 31.6 mm
Pedals
Freeridepedal, Aluminium, mit Reflektor
Clamping Ring
Internal hexagon, 34.9 mm
Engine
Yamaha, PW-X2, 250 W, 80 Nm, 25 km/h
Weight (Kg)
23.3 kg
Permitted Total Weight
120.0 kg
Battery
Yamaha, Lithium Ion, 500 Wh
